60CM BLACK WINE COOLER (F RATED)
WRBKWC60F
Drawing 1
Drawing 1 | Item# | Part Details | Availability | £ | |
|---|---|---|---|---|
| Drawing 1 | ||||
| 1.2.0520.0075
CONTROL PCB BRACKET | Low Stock | 4.99 | ||
| 1.1.0520.0612
LEFT ULOWER HINGE | Low Stock | 6.99 | ||
| Accessory | 1.1.0520.0610
LEFT UPPER HINGE | Not Available | ||
| 1 | 1.3.0220.0041
POWER CORD | Low Stock | 12.49 | |
| 2 | 1.1.0220.0062
DRY FILTER | In Stock | 10.99 | |
| 3&4 | 1.3.0100.0063
COMPRESSOR ASSY | On Order | 60.00 | |
| 5 | 1.2.0520.0011
POWER BOARD PROTECTIVE COVER | Low Stock | 4.99 | |
| 6 | 1.3.0420.0096
POWER BOARD | In Stock | 45.99 | |
| 8 | 1.2.0520.0029
DECORATION PLUG | Low Stock | 3.99 | |
| 9 | 1.1.0520.0606
RIGHT UPPER HINGE | Not Available | ||
| 10 | 1.1.0220.0044
EVAPORATOR | Not Available | ||
| 11 | 1.3.0320.0275
AIR THERMISTOR | In Stock | 12.99 | |
| 12 | 1.2.0520.0022
AIR THERMISTOR COVER | Low Stock | 3.99 | |
| 13 | 1.2.0520.0023
SCREW OF AIR THERMISTOR COVER | Not Available | ||
| 14&30 | 1.3.0620.0001
INTERIOR FAN MOTOR?CHA12012BL-25B | In Stock | 19.99 | |
| 15 | 1.2.0220.0002
AIR DUCT | Low Stock | 12.99 | |
| 16 | 1.2.0520.0039
CONTROL PCB BRACKET | Low Stock | 3.99 | |
| 17 | 1.3.0420.0014
CONTROL PCB | Low Stock | 29.99 | |
| 18 | 1.1.0820.0356
AIR DUCT | Not Available | ||
| 19 | 1.6.0120.0056
SPACER POLYFOAM | Not Available | ||
| 20 | 1.6.0720.0272
CONTROL PANEL STICKER | Not Available | ||
| 21 | 1.2.0520.0038
SHELF LIMIT COLUMN | Low Stock | 3.99 | |
| 22 | 1.5.0120.0010
SHELF | In Stock | 15.00 | |
| 23.1 | 1.1.0720.0055
HANDLE | In Stock | 18.99 | |
| 23.2 | 1.2.0320.0004
DOOR SEAL | Not Available | ||
| 23.3 | 1.4.0320.0042
GLASS DOOR | On Order | Contact Us | |
| 24 | 1.1.0520.0005
DOOR SHAFT ASSEMBLY | In Stock | 4.99 | |
| 25 | 1.5.0120.0006
BOTTOM SHELF | In Stock | 11.99 | |
| 26 | 1.1.0820.0009
AIR DUCT | Low Stock | 12.99 | |
| 27&36 | 1.2.0520.0016
LED LAMP COVER | Low Stock | 3.99 | |
| 28&37 | 1.3.0520.0078
LED LAMP BOARD | Not Available | ||
| 29 | 1.2.0520.0192
LED LAMP BOX | Not Available | ||
| 31 | 1.1.0320.0383
BASE GRILLE | On Order | 17.49 | |
| 32 | 1.2.0520.0402
FILTER CARBON BOX | Low Stock | 15.99 | |
| 33 | 1.3.0620.0004
PTC HEATING ELEMENT FAN?HSP8015MB | In Stock | 9.99 | |
| 34 | 1.2.0520.0026
WATER DRIP TRAY | Low Stock | 3.99 | |
| 35 | 1.1.0520.0608
RIGHT LOWER HINGE | On Order | Contact Us | |
| 38 | 1.3.0420.0047
PTC HEATING ELEMENT | In Stock | 19.99 | |
| 39 | 1.3.0620.0058
CONDENSER FAN?HSP12025MS | Not Available | ||
| 40 | 1.1.0220.0025
CONDENSER | Not Available | ||
| 41 | 1.2.0520.0205
SUCTION PIPE | Not Available | ||
| 42 | 1.1.0320.0181
COMPRESSOR BASE | Not Available | ||
| 43 | 1.2.0520.0024
WATER DRIP TRAY | Low Stock | 3.99 | |
| 44 | 1.1.0220.0015
CONNECTING PIPE | Not Available | ||
| 45 | 1.1.0220.0007
COPPER PIPE (EXHAUST PIPE) | Not Available | ||
